The HP MSR3000 Router Series, the next generation of router from HP, is a component of the HP FlexBranch solution, which is a part of the comprehensive HP FlexNetwork architecture. These routers feature a modular design that delivers unmatched application services for medium- to large-sized branch offices. This gives your IT personnel the benefit of reduced complexity, and simplified configuration, deployment, and management.
The MSR3000 routers use the latest multicore CPUs, offer Gigabit switching, provide an enhanced PCI bus, and ship with the latest version of HP Comware software to help ensure high performance with concurrent services. The MSR3000 series provides a full-featured, resilient routing platform, including IPv6 and MPLS, with up to 5 Mpps forwarding capacity and 3.3 Gb/s of IPSec VPN encrypted throughput. These routers also support HP Open Application Platform (OAP) modules to deliver integrated industry-leading HP AllianceOne partner applications such as virtualization, unified communications and collaboration (UC&C), and application optimization capabilities.
The MSR3000 series provides an agile, flexible network infrastructure that enables you to quickly adapt to changing business requirements while delivering integrated concurrent services on a single, easy-to-manage platform.
- General Information
- Manufacturer
- Hewlett Packard Enterprise
- Manufacturer Website Address
- http://www.hpe.com
- Brand Name
- HPE
- Product Series
- MSR3000
- Product Type
- Wireless Router
- Wireless Specifications
- Broadband Transmission Technology
- Cellular
- Ethernet
- ISM Band
- No
- UNII Band
- No
- Cellular Generation
- 3G
- Features
- Quality of Service (QoS)
- Interfaces/Ports
- Network (RJ-11)
- No
- VGA
- No
- Serial
- Yes
- USB
- Yes
- Powerline
- No
- Management Port
- Yes
- Number of Broadband (RJ-45) Ports
- 3
- I/O Expansions
- Total Number of Expansion Slots
- 5
- Expansion Slot Type
- Smart Interface Card (SIC)
- SFP (mini-GBIC)
- High-performance Multifunction Interface Module (HMIM)
- Network & Communication
- Ethernet Technology
- Gigabit Ethernet
- Network Technology
- 10/100/1000Base-T
- VPN Supported
- Yes
- Management & Protocols
- Management
- HP Intelligent Management Center (IMC)
- Command Line Interface (CLI)
- SNMP v1/2/3
- RMON
- MIB II
- VLAN
- Security Features
- IEEE 802.1X
- RFC 2104 Keyed-Hashing for Message Authentication
- IKE
- Access Control List
- EAP
- TLS
- RADIUS
- Firewall
- NAT
- IPSec
- TACACS+
- AAA
- DES
- 3DES
- AES 128/192/256-bit
- SHA-1
- MD5
- Power Description
- Input Voltage
- 110 V AC
- 220 V AC
- Power Source
- AC Supply
- Physical Characteristics
- Rack Height
- 1U
- Form Factor
- Rack-mountable
- Desktop
- Height
- 44.2 mm
- Width
- 439.9 mm
- Depth
- 480.1 mm
- Weight (Approximate)
- 7.15 kg
- Miscellaneous
- Certifications & Standards
- Safety:
- UL 60950-1
- AS/NZS 60950
- EN 60825-1 Safety of Laser Products-Part 1
- EN 60825-2 Safety of Laser
- Products-Part 2
- IEC 60950-1
- CAN/CSA-C22.2 No. 60950-1-03
- EN 60950-1/A11
- FDA 21 CFR Subchapter J
- EN 55022 Class A
- ICES-003 Class A
- ANSI C63.4 2003
- ETSI EN 300 386 V1.3.3
- AS/NZS CISPR 22 Class A;
- EN 61000-4-2
- EN 61000-4-3
- EN 61000-4-4
- EN 61000-4-5
- EN 61000-4-6
- EN 61000-3-2:2006
- EN61000-3-3:1995 +A1:2001+A2:2005
- EMC Directive 2004/108/EC
- FCC (CFR 47, Part 15) Class A
- EN55024:1998+ A1:2001 + A2:2003
- EN 61000-4-11:2004
- EN 61000-4-8:2001
- Environmentally Friendly
- Yes
