The HP A-MSR20-1x Series is a set of full-featured, economical routers designed for converged WAN, wired, and wireless LAN traffic at enterprise branch locations and small to medium-sized businesses. They deliver high performance while reducing complexity, simplifying management, and increasing control. These routers enable an agile and flexible network infrastructure that can quickly adapt to changing business requirements, while delivering integrated, concurrent services on a single, easy-to-manage platform.
- General Information
- Manufacturer
- Hewlett Packard Enterprise
- Manufacturer Website Address
- http://www.hpe.com
- Brand Name
- HPE
- Product Series
- A-MSR20-1x
- Product Type
- Wireless Router
- Wireless Specifications
- Wireless LAN Standard
- IEEE 802.11b/g
- ISM Band
- Yes
- ISM Maximum Frequency
- 2.40 GHz
- Total Wireless Transmission Speed
- 6.75 MB/s
- Interfaces/Ports
- Fast Ethernet Port
- Yes
- Serial
- Yes
- Management Port
- Yes
- Number of Broadband (RJ-45) Ports
- 5
- I/O Expansions
- Total Number of Expansion Slots
- 1
- Network & Communication
- Ethernet Technology
- Fast Ethernet
- Management & Protocols
- Management
- NAT
- CHAP
- L2TP
- NAT-PT
- IP Security
- DES-CBC
- Port Based Network Access Control
- AES
- Security Features
- NAT
- CHAP
- L2TP
- NAT-PT
- IP Security
- DES-CBC
- Port Based Network Access Control
- AES
- Physical Characteristics
- Rack Height
- 1U
- Form Factor
- Rack-mountable
- Desktop
- Height
- 44.2 mm
- Width
- 300 mm
- Depth
- 240 mm
- Weight (Approximate)
- 3 kg
- Miscellaneous
- Certifications & Standards
- IEEE 802.3
- IEEE 802.3u
- IEEE 802.11b
- IEEE 802.11g
Safety
- UL 60950-1
- AS/NZS 60950
- EN 60825-1 Safety of Laser Products-Part 1
- EN 60825-2 Safety of Laser Products-Part 2
- IEC 60950-1
- CAN/CSA-C22.2 No. 60950-1-03
- EN 60950-1/A11
- FDA 21 CFR Subchapter J
Emissions
- EN 55022 Class B
- ICES-003 Class B
- ANSI C63.4 2003
- ETSI EN 300 386 V1.3.3
- EN 61000-4-2
- EN 61000-4-3
- EN 61000-4-4
- EN 61000-4-5
- EN 61000-4-6
- EN 61000-3-2:2006
- EN 61000-3-3:1995 +A1:2001+A2:2005
- EMC Directive 2004/108/EC
- EN 55024:1998+ A1:2001 + A2:2003
- EN 61000-4-11:2004
- EN 61000-4-8:2001
- AS/NZS CISPR22 Class B
- FCC (CFR 47, Part 15) Class B
Telecom
- FCC part 68
- Environmentally Friendly
- Yes
