- General Information
- Manufacturer
- Hewlett Packard Enterprise
- Manufacturer Website Address
- http://www.hpe.com
- Brand Name
- HPE
- Product Line
- FlexFabric
- Product Series
- 5944
- Product Type
- Ethernet Switch
HPE FlexFabric 5944 Switch Series
HPE FlexFabric 5944 Switch Series is a family of high-density, ultra-low-latency ToR switches Ideally suited for deployment at the aggregation and server access or leaf layer of large enterprise data centers and cloud service provider environments, the HPE FlexFabric 5944 Switch Series is also powerful enough for deployment at the core layer of medium-sized enterprises.
Delivering high performance switching capacity with the latest generation of ASICs,10G-BaseT connectivity, Virtual Extensible LAN (VXLAN) , Multiprotocol Lable Switching (MPLS) and Multicast, the 5944 Switch series offers a choice that fits your budget and delivers low TCO. The 5944 Switch series includes HPE FlexFabric Network Analytics that enhances visibility and network manageability with real-time telemetry collection and analysis.
- Interfaces/Ports
- Total Number of Network Ports
- 48
- Uplink Port
- Yes
- Modular
- Yes
- Network (RJ-45)
- Yes
- Port/Expansion Slot Details
- 48 x 10 Gigabit Ethernet Network
- 6 x 100 Gigabit Ethernet Expansion Slot
- Media & Performance
- Media Type Supported
- Optical Fiber
- Twisted Pair
- Ethernet Technology
- 10 Gigabit Ethernet
- 100 Gigabit Ethernet
- Network Technology
- 10GBase-T
- 100GBase-X
- I/O Expansions
- Total Number of Expansion Slots
- 6.0
- Expansion Slot Type
- QSFP28
- Network & Communication
- Layer Supported
- 3
- Networking Standards
- IEEE 802.1Qbb
- IEEE 802.1Qaz
- IEEE 802.3x
- IEEE 802.3ad
- IEEE 802.1D
- IEEE 802.1w
- IEEE 802.1s
- IEEE 802.1ag
- IEEE 802.3ah
- IEEE 802.1x
- IEEE 802.1ab
- IEEE 802.1ad
- IEEE 802.1AX
- IEEE 802.1p
- IEEE 802.1Q
- IEEE 802.3ae
- Management & Protocols
- Manageable
- Yes
- Power Description
- Frequency
- 50 Hz
- 60 Hz
- Power Source
- Power Supply
- Redundant Power Supply Supported
- Yes
- Number of Power Supplies Supported
- 2
- Power Consumption
- 102 W
- Physical Characteristics
- Compatible Rack Unit
- 1U
- Form Factor
- Rack-mountable
- Height
- 44 mm
- Width
- 460 mm
- Depth
- 440 mm
