- General Information
- Manufacturer
- Eaton Corporation
- Manufacturer Website Address
- http://www.powerquality.eaton.com/UK/
- Brand Name
- Eaton
- Product Type
- PDU
- Technical Information
- PDU Type
- Metered
- Phase
- Three Phase
- Plug/Connector Type
- IEC 60309 63A 3Ph
- Receptacle Type
- IEC 60320 C13
- IEC 60320 C19
- Receptacle Detail
- 18 x IEC 60320 C13
- 12 x IEC 60320 C19
- Protection Type
- Circuit Breaker
- Single Pole
- Locking Receptacles
- P-Lock
- Features
- LCD Display
- Power Description
- Input Voltage Range
- 346 V AC - 415 V AC
- Power Rating (Watt)
- 43.60 kW
- Input Current
- 63 A
- Input Frequency
- 60 Hz
- Circuit Breaker
- Yes
- Management
- Remote Outlet Switching
- No
- Interfaces/Ports
- Network (RJ-45)
- Yes
- Physical Characteristics
- Color Family
- Black
- Product Color
- Black
- Mounting Orientation
- Vertical
- Mount Type
- Rack-mountable
- Form Factor
- Vertical
- Rack Height
- 0U
- Cord Length
- 3 m
- Height
- 52 mm
- Width
- 65 mm
- Depth
- 1829 mm
- Weight (Approximate)
- 10.20 kg
- Environmental Conditions
- Minimum Operating Temperature
- 0°C
- Maximum Operating Temperature
- 60°C
- Miscellaneous
- Package Contents
- 30-Outlets PDU
- Mounting Accessories
- Network Cable
- Configuration Cable
- Splitter for Daisy-Chaining
- Quickstart Guide
- Safety Instructions
- Environmentally Friendly
- Yes
- Environmental Compliance
- Restriction of Hazardous Substances (RoHS)
