- General Information
- Manufacturer
- ASUS Computer International
- Manufacturer Website Address
- http://uk.asus.com
- Brand Name
- Asus
- Product Type
- Desktop Motherboard
- Processor & Chipset
- Chipset Manufacturer
- Intel
- Chipset Model
- H81
- Total Processor Supported
- 1
- Processor Socket
- Socket H3 LGA-1150
- Processor Supported
- Core i7
- Core i5
- Core i3
- Pentium
- Celeron
- 64-bit Processing
- Yes
- Memory
- Number of Memory Slots
- 2
- Memory Form Factor
- DIMM
- Maximum Memory Supported
- 16 GB
- Memory Standard
- DDR3-1600/PC3-12800
- DDR3-1333/PC3-10600
- DDR3-1066/PC3-8500
- Memory Technology
- DDR3 SDRAM
- Memory Speed Supported
- 1600 MHz
- 1333 MHz
- 1066 MHz
- I/O Controller
- Controller Type
- Serial ATA/600
- Serial ATA/300
- Video
- Onboard Video
- CPU Dependent Video
- Graphics Controller Memory
- 1 GB
- Audio
- Sound Controller Model
- ALC887
- Audio Channels
- 7.1
- Network & Communication
- Gigabit Ethernet
- Yes
- I/O Expansions
- Total Number of Expansion Slots
- 3
- Total Number of PCI Express Slots
- 3
- Number of PCI Express x1 Slots
- 2
- Number of PCI Express x16 Slots
- 1
- Interfaces/Ports
- Total Number of USB Ports
- 4
- Number of USB 2.0 Ports
- 2
- Number of USB 3.0 Ports
- 2
- Audio Line In
- Yes
- Audio Line Out
- Yes
- Microphone Port
- Yes
- VGA
- Yes
- DVI
- Yes
- Number of DVI Outputs
- 1
- Network (RJ-45)
- Yes
- Number of Network (RJ-45) Ports
- 1
- PS/2 Port
- Yes
- Number of PS/2 Ports
- 2
- Onboard Interfaces
- Number of SATA Interfaces
- 4
- Total Number of Onboard USB Ports
- 4
- Number of Onboard USB 2.0 Ports
- 4
- Onboard Audio Header
- Yes
- Onboard S/PDIF Header
- Yes
- Power Description
- Power Supply Supported
- ATX12V
- Physical Characteristics
- Form Factor
- Flex ATX
- Width
- 226 mm
- Depth
- 175 mm
- Miscellaneous
- Certifications & Standards
- ACPI 2.0a
- Environmentally Friendly
- Yes
