- General Information
- Manufacturer
- Schneider Electric SA
- Manufacturer Website Address
- http://www.schneider-electric.com
- Brand Name
- APC by Schneider Electric
- Product Line
- Easy UPS On-Line
- Packaged Quantity
- 1 / Pack
- Product Type
- Double Conversion Online UPS
- Warranty
- Limited Warranty
- 60 Month
- Technical Information
- Plug/Connector Type
- IEC 60320 C20
- Receptacle Type
- IEC 60320 C13
- Receptacle Detail
- 6 x IEC 60320 C13
- Phase
- Single Phase
- Power Description
- Load Capacity (VA)
- 2 kVA
- Load Capacity (Watt)
- 1.80 kW
- Input Voltage
- 230 V AC
- 120 V AC
- Input Voltage Range
- 160 V AC - 300 V AC
- 110 V AC - 300 V AC
- Output Voltage
- 230 V AC
- 220 V AC
- 240 V AC
- Input Frequency
- 40 Hz
- 70 Hz
- Output Frequency
- 50 Hz
- 60 Hz
- Waveform Type
- Sine Wave
- Surge Energy Rating
- 945 J
- Display & Graphics
- Display
- LCD
- Management
- Network Management
- Intelligent Card Slot
- Alarm
- Low Battery
- Overload
- Interfaces/Ports
- Serial Port
- Yes
- USB
- Yes
- Battery Information
- DC System Voltage
- 48 V DC
- Battery Characteristics
- Internal Battery
- Battery Chemistry
- Lithium Ion (Li-Ion)
- Battery Energy
- 1440 kJ
- Backup/Run Time (Full Load)
- 10.10 Minute
- Backup/Run Time (Half Load)
- 20.48 Minute
- Battery Life
- 10 Year
- Typical Battery Recharge Time
- 1.50 Hour
- Replaceable Battery
- Yes
- Environmental Conditions
- Minimum Operating Temperature
- 0°C
- Maximum Operating Temperature
- 40°C
- Storage Temperature
- -20°C - 50°C
- Maximum Operating Elevation
- 3 km
- Maximum Storage Elevation
- 15 km
- Storage Relative Humidity
- 0% - 95%
- Sound Emission (A-Weighted)
- 50 dB(A)
- Thermal Dissipation
- 683 BTU/h
- Physical Characteristics
- Color Family
- Dual Colour
- Product Color
- Black
- Silver
- Height
- 86 mm
- Width
- 438 mm
- Depth
- 502 mm
- Rack Height
- 2U
- Form Factor
- Rack/Tower
- Mounting Location
- Horizontal/Vertical
- Weight (Approximate)
- 16.50 kg
- Miscellaneous
- Package Contents
- Easy UPS On-Line 2000VA Rack/Tower UPS
- Basic UPS Signaling Cable, RS-232
- USB Cable
- C13-C14 Power Cable
- IEC-C20 - Schuko Input Power Cable
- Rack Mounting Brackets
- Rack Mounting Rails
- Stabilizing Feet
- User Manual
- Safety Guide
- Certifications & Standards
- CB
- CE
- UKCA
- UN 38.3
- IEC 62619
- IP20
- Environmental Compliance
- Restriction of Hazardous Substances (RoHS)
- Registration, Evaluation, Authorization and Restriction of Chemicals (REACH)
- Waste Electrical and Electronic Equipment Directive (WEEE)
